| Model | AW65 |
| Operating load (kg) | 1050 |
| Max Speed（km/h） | 10 |
| Rated flux (L/min) | 89 |
| Tire（track） model | 12-16.5NHS |
| Rated power (Kw) | 55KW |
| Fuel tank capacity (L) | 75 |
| Gross weight (kg) | 3300 |
| Operating weight (kg) | 3400 |
| Bucket capacity (m³) | 0.5 |
| Overall operating height (mm) | 3987 |
| Height to bucket hinge pin (mm) | 3018 |
| Hheight to top of cab (mm) | 2295 |
| Height to bottom of level bucket(mm) | 2862 |
| Without bucket length（mm） | 2527 |
| Overall length with bucket(mm) | 3428 |
| Dumping angle at maximum height(° ) | 32 |
| Dumping height(mm) | 2410 |
| Dumping reach(mm) | 850 |
| Rollback o bucket on ground(° ) | 23 |
| Rollback of bucket at full height(° ) | 95 |
| Wheelbase(mm) | 1074 |
| Ground clearance(mm) | 205 |
| Angle of departure(° ) | 20 |
| Front turning radius without bucket(mm) | 1320.5 |
| Front tuning radius(mm) | 2096.5 |
| Rear tuning radius(mm) | 1647.5 |
| Rear axle to bumper (mm) | 1057 |
| Tread width (mm) | 1498 |
| Width (mm) | 1805 |
| Bucket width (mm) | 1880 |
HE65 skid steer loader
Skid steer loader
Our advanced HE65W skid steer loader is engineered to deliver exceptional performance across construction, agriculture and material handling applications. Combining robust power, compact design and unmatched maneuverability, it is the ideal solution for demanding jobsites.
Key Features
1.High-Performance Engine Options
.Equipped with a reliable 55kW(74hp)engine, offering superior fuel efficiency and low emissions.
.Engine options: Xinchai or Cummins engines ensure flexibility to meet diverse customer preferences and regional requirements.
2.Durable & Compact Design
.Operating Weight: 3,400kg
-Strikes the perfect balance between stability and agility.
.Rugged chassis and reinforced components for extended durability in harsh environments.
- Outstanding Versatility
.Quick-attach system supports a wide range of attachments(buckets, augers, pallet forks etc.) enabling multi-functional use for digging, lifting, grading and more.
.Zero-radius turning capability for seamless operation in confined spaces.
- Operator Comfort & Safety
.Ergonomic ROPS/FOPS-certified cab with intuitive controls, adjustable seating and excellent visibility.
.Advanced hydraulic system ensures smooth and precise operation.
- Low Maintenance & Cost-Effective
. Easy-access service points simplify routine maintenance.
. Optimized powertrain design reduces long-term operating costs.
Technical Specifications
. Rated Power: 55kW/74hp
. Operating Weight: 3,400kg
. Engine Options: Xinchai or Cummins Tier3/StageIIIA compliant
. Bucket Capacity: 0.5m³
[video width="1280" height="720" mp4="https://hexcamachines.com/wp-content/uploads/2025/05/WeChat_20241013103304.mp4"][/video]
. Travel speed: 12km/h
Applications
Ideal for construction sites, landscaping projects, agriculture tasks, snow removal, and industrial material handling.
Why Choose Our Skid Steer Loader ?
. Proven Reliability: Built to withstand rigorous daily operations.
. Global Engine Support: Xinchai and Cummins networks ensure worldwide parts and service accessibility.
. Ec0-Friendly: Compliant with international emission standards.
-
