HE230J Heavy-Duty Excavator: 1.1m³ Bucket, 124KW Engine

Excavators

The HE230J is a versatile machine designed for efficient performance in challenging excavation tasks. With a 1.1 m³ bucket capacity and a robust 124 KW engine, it offers the strength required for heavy-duty operations.

Built for durability and reliability, the HE230J is an excellent choice for demanding work environments. Its advanced capabilities make it suitable for large-scale projects, delivering consistent results across various terrains

Bucket Capacity

1.1 m³

Engine Model

05B7

Power

124 KW

Inquire Now

Product Description Specifications: Bucket Capacity: 1.1 m³ Swing Speed: 11-13 RPM Gradeability: 30° Max. Bucket Digging Force: 140 KN Max. Arm Digging Force: 99 KN Engine Model: 05B7 Power/Revolution Speed: 124 KW/2050 RPM System Pressure: 34 MPa Machine Size: Dimension (LWH): 9590*2980*3185 mm Cabin Height: 3060 mm Axle Base: 3655 mm Wheel (Track) Distance: 2380 mm Minimum Ground Clearance: 470 mm Tail Swing Radius: 2880 mm Working Range: Min. Swing Radius: 3555 mm Max. Digging Height: 9410 mm Max. Dumping Height: 6730 mm Max. Digging Depth: 6480 mm Max. Vertical Digging Depth: 5925 mm Max. Digging Radius: 9850 mm
